| Bremsen hinten | Magura MT7, 4-piston caliper, hydraulic disc, 203mm |
| Bremsen vorne | Magura MT7, 4-piston caliper, hydraulic disc, 203mm |
| Rahmen | M5 alloy, Style-Specific DH Geometry, horst pivot flip chip for 27.5 or 29 rear wheel, BSA threaded BB, full internal cable routing with option for full external brake, 148mm rear spacing, sealed cartridge bearing pivots, replaceable derailleur hanger, 200mm of travel |
| Schaltung | SRAM X01 DH, 7-speed, trigger |
| Schalthebel | SRAM X01 DH, trigger, 7-speed |
| Gabel | Öhlins DH38 M.1 29, TTX Twin Tube Damping, external low speed rebound adjust, external high and low speed compression adjustment, 20x110mm, 58mm offset, 200mm of travel |
| Dämpfer | Öhlins TTX 22 M Coil, external rebound adjust, external high and low speed compression adjustment, Trunnion mount, 225x75 |
| Innenlager | SRAM DUB, 83mm |
| Lenker | Renthal Fatbar35, 5-degree upsweep, 7-degree backsweep, 30mm rise, 800mm, 35.0mm |
| Vorbau | Renthal Integra35, Direct Mount Stem, 45mm length |
| Sattelmodell | Body Geometry Henge DH, hollow titanium rails, 130mm |
| Sattelstütze | Thomson, alloy, straight, 12-degree clamp |
| Sattelklemmung | Specialized Alloy, 34.9mm |
| Felgen | Roval 29" Alloy DH, 28mm internal width, 28h front, 32h rear, tubeless ready |
| Reifen vorne | Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3" |
| Reifen hinten | Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 27.5x2.3" |
| Nabe vorne | Alloy, sealed cartridge bearings, 20x110mm, 28h |
| Nabe hinten | DT Swiss 350, SRAM XD freehub, 6-bolt disc, high-low flange, sealed cartridge bearings, 12x148mm spacing, 32h |
| Speichen | DT Swiss Competition, stainless steel, 14g |
