Brakes	Shimano M4100 / MT420 4-Piston
Frame	Macina Chacana 29" Alloy 6061 SLL-E 125mm UDH; PT750 Bosch Ge
Drivetrain	Shimano Deore XT M8100-12 SGS shadow+
Shift levers	Shimano Deore M6100-12
Fork	RockShox 35 Silver TK 29" 130mm 15x110 taper
Rear shock	RockShox Deluxe Select+ 230x57.5
Crankset	KTM E-RACE ISIS 170mm Q2
Sprocket	Shimano Deore M6100-12 / 10-51
Drive	Shimano M6100-12
Headset	Acros AICR internal 1.1/8"-1.5" angle limit
Handlebar	KTM COMP Trail35 rizer15 760mm
Grips	Ergon GA20
Stem	KTM TEAM Trail35
Saddle	Selle San Marco RND Manganes Rails
Seatpost	KTM COMP dropper internal 30.9 T:150
Seat clamp	KTM Line JD-SC140A - 35.0mm
Wheelset	Front wheel: KTM Line - Shimano TC500B CL 32H 110-15TA, Ambrosio E30 Trail 32H 622x30TC, DT Champion 2.0 black - HR: KTM Line - Shimano TC500B CL 32H 148-12TA, Ambrosio E30 Trail 32H 622x30TC, DT Alpine II 2.34 black
Front tire	Schwalbe Johnny Watts Perf. DD RaceGuard 60-622 Reflex
Rear tire	Schwalbe Johnny Watts Perf. DD RaceGuard 60-622 Reflex
Pedals	MTB pedal flat VPE-527 alloy
Front light	Litemove SEC-150 150 lux down
Mudguards	Racktime Aluminium 72mm B&M Xeltec
Kickstand	KTM 28" adjustable MY2025
Rack	Racktime Alumee rails (platform option)
Motor manufacturer / model	Bosch PERFORMANCE CX BDU3740 – 25 km/h / 85 Nm
Display	Bosch LED remote / Bosch KIOX 300 TFT display
Battery	Bosch PowerTUBE 750Wh (horizontal)
Battery capacity (Wh)	750
Charger	Bosch STANDARD Charger 4A

KTM MACINA CHACANA 792 LFC
