Bikefinder: Which bike is right for you?

Brakes	Shimano Deore XT T8100 / M8120 4-piston
Front brake disc	Shimano MT800 CL 203 freeza
Rear brake disc	Shimano EM810 CL 180 magnet
Frame	Macina Chacana 29" Alloy 6061 125 UDH\|PT750 Bosch BDU37/M2286
Frame material	Aluminium
Drivetrain	Shimano CUES Di2 U8050-11 SGS shadow
Shift levers	right: Shimano MT500 SP-Lever - left: Shimano CUES Di2 EN605 Switch
Drivetrain type	Derailleur
Fork	FOX 34 Float AWL 29" E 130mm 15x110
Rear shock	FOX Float DPS Performance 230x57.5
Crankset	left: KTM E-TEAM ISIS 170mm Q16 - right: KTM E-TEAM ISIS 170mm Q16
Sprocket	Shimano LG400-11 / 11-50
Drive	KMC e500 LG e-bike
Drive type	Chain
Headset	Acros AICR internal 1.1/8"-1.5" angle lim
Handlebar	KTM COMP Trail35 rizer15 760mm
Grips	Ergon GA20
Stem	KTM TEAM Trail35
Saddle	Selle Royal Lookin Athletic 3D
Seatpost	KTM COMP dropper internal 30.9 T:150
Seat clamp	KTM Line JD-SC140A - 35.0mm
Wheel size	29"/622mm
Front tire	Schwalbe Johnny Watts Perf. DD RaceGuard 60-622 Reflex
Rear tire	Schwalbe Johnny Watts Perf. DD RaceGuard 60-622 Reflex
Front hub	Shimano TC500B CL 32H 110-15TA
Rear hub	Shimano TC500B CL 32H 148-12TA
Spokes	front: DT Champion 2.0 black - rear: DT Alpine II 2.34 black
Pedals	MTB pedal flat VPE-527 alloy
Front light	Litemove AE-130 90–130 lux HighBeam
Mudguards	front: Racktime Aluminium 72mm - rear: Racktime Aluminium 72mm B&M Xeltec
Kickstand	KTM 28" adjustable
Rack	Racktime Alumee rails (platform option)
Motor manufacturer / model	Bosch PERFORMANCE CX BDU3740
Display	Bosch KIOX 300 TFT display
Battery	Bosch PowerTUBE 750Wh horizontal - ABUS integrated lock IT1 (X-Plus key)
Battery capacity (Wh)	750
Charger	Bosch STANDARD Charger 4A

KTM MACINA CHACANA 791 LFC Di2
