Brakes	Shimano Saint M820 / M820 4-Piston
Front brake disc	Shimano MT800 CL 203 freeza
Rear brake disc	Shimano EM810 CL 180 magnet
Frame	Macina Prowler Dimmix Carbon 170 UDH\|PT750 Bosch BDU37/M2236
Frame material	Carbon
Drivetrain	Shimano Deore Di2 M6260-11 LG SGS shad+
Shift levers	right: Shimano MT500 SP-Lever - left: Shimano Deore Di2 M6250
Drivetrain type	Derailleur
Fork	FOX 38 Float 29" Perf E 180mm 15x110
Rear shock	FOX DHX2 PerformanceElite 2-position 250x75
Crankset	left: KTM E-TRAIL ISIS 160mm Q16 - right: KTM E-TRAIL ISIS 160mm Q16
Sprocket	Shimano LG400-11 / 11-50
Drive	KMC e500 LG e-bike
Drive type	Chain
Headset	Acros AICR internal 1.1/8"-1.5" angle lim
Handlebar	KTM PRIME Trail35 Carbon Rizer20 800mm
Grips	Ergon GA20
Stem	KTM TEAM Trail35
Saddle	Selle San Marco Ground Short Open Fit Narrow
Seatpost	FOX Transfer Performance (internal)
Seat clamp	KTM Line JD-SC140A - 35.0mm
Wheelset	front: KTM E-TEAM Trail 29 CL 110/15TA\|622x30TC TLR by DT - rear: KTM E-TEAM Trail 27 CL 148/12TA\| 622x35TC TLR by DT
Wheel size	29"/622mm, 27.5“/584mm
Front tire	Schwalbe Eddy Current Front Evo SuperTrail TLE 65-622
Rear tire	Schwalbe Eddy Current Rear Evo SuperGravity TLE 70-584
Pedals	MTB pedal flat VP-539 nylon
Motor manufacturer / model	Bosch PERFORMANCE CX BDU3740
Display	Bosch KIOX 300 TFT display
Battery	Bosch PowerTUBE 750Wh horizontal - ABUS integrated lock IT1 (X-Plus key)
Battery capacity (Wh)	750
Charger	Bosch STANDARD Charger 4A

KTM MACINA PROWLER PRESTIGE 750 Di2
