| Rear brakes | Hydraulic disc brake Shimano MT200 // Hydraulic disc brake Shimano MT200
Shimano EM300, centre lock disc mount, 160 mm // Shimano RT10, centre lock disc mount, 160 mm |
| Front brakes | Hydraulic disc brake Shimano MT200 // Hydraulic disc brake Shimano MT200
Shimano EM300, centre lock disc mount, 160 mm // Shimano RT10, centre lock disc mount, 160 mm |
| Frame | High-performance aluminium frame with hydroformed tubes, removable integrated battery (RIB), internal cable routing, motor armour, post mount disc brake mount |
| Frame material | Aluminium |
| Shift levers | Shimano Nexus C7000, 5-speed |
| Number of gears | 1 |
| Fork | SR Suntour NVX30, coil spring, adjustable spring preload, 100 mm quick-release axle, 60 mm travel |
| Crankset | ProWheel, aluminium, 175 mm crank arm length |
| Sprocket | Shimano C7000 sprocket for Nexus, 27 t. |
| Drive | Shimano HG40, 6/7/8-speed |
| Drive type | Chain |
| Handlebar | Aluminium, 31.8 mm clamping, 25 mm rise, 630 mm width |
| Grips | Bontrager Satellite Elite, aluminium clamp |
| Stem | Bontrager aluminium, 31.8 mm, adjustable, Blendr compatible |
| Saddle | Bontrager Boulevard |
| Seatpost | Aluminium, sprung, 31.6 mm, 300 mm length |
| Wheelset | Bontrager Connection, hollow chamber rim, 32-hole, 20 mm inner width, Presta valve
Aluminium, Centerlock disc mount, 100 mm thru axle
Shimano Nexus C7000, 5-speed |
| Wheel size | 28"/622mm |
| Tires | Bontrager E6 Hard-Case Lite, reflector stripes, 27.5 x 2.40 |
| Pedals | Bontrager City Pedals |
| Front light | Spanninga SOLO for e-bikes // Herrmans Nordic MR5-E, 140lumen, LED |
| Mudguards | SKS plastic, rear // SKS plastic, front |
| Kickstand | Pletscher Comp Flex 18 |
| Rack | Rear luggage rack made of aluminium, 25 kg max. load |
| Motor manufacturer / model | Bosch Performance Line, 250 W, 75 Nm, 25 km/h |
| Motor type | up to 25 km/h |
| Display | Bosch Intuvia 100, smart system |
| Battery | 545 Wh |
| Battery capacity (Wh) | 545 |
| Battery mount | Gepäckträger |
| Charger | Bosch standard charger 4 A, 230 V, Smart System |
