Specialized S-Works Crux Red AXS
Model: S-Works Crux Red AXS
Model year: 2026
Category: Gravel
Frame material: Carbon
Weight: 7.33 kg
Wheel size: 28"/622mm
Test result
| Property | Weighting | Grade |
|---|---|---|
| Lab | 75% | 1,8 |
| Complete bike weight | 25% | 1,0 |
| Rear comfort | 20% | 2,3 |
| Front comfort | 10% | 2,3 |
| Acceleration | 10% | 2,3 |
| Ride stability | 10% | 1,7 |
| Equipment | 25% | 1,4 |
| Brakes | 5% | 1,0 |
| Shifting | 5% | 1,5 |
| Tires | 5% | 1,5 |
| Paint | 5% | 1,0 |
| Maintenance / Adjustments | 5% | 2,0 |
| Final grade | 1,7 |
Strengths and weaknesses
| Complete bike weight | 7330 g |
| Ride stability | 8,01 N/mm |
| Rear comfort | 146,82 N/mm |
| Front comfort | 84,24 N/mm |
| Sprint / BB stiffness | 52 N/mm |
Geometry - measurements overview
H
G
A
J
C
I
B
E
D
F
K
L
56cm
| A - Head tube length | 142 mm |
| B - Seat tube length | 495 mm |
| C - Wheelbase | 1039 mm |
| D - Top tube length | 570 mm |
| E - Stack | 585 mm |
| F - Stack+ | 643 mm |
| G - Reach | 397 mm |
| H - Reach+ | 568 mm |
| I - Seat angle | 73 ° |
| J - Head angle | 72 ° |
| K - STR | 1.47 |
| L - STR+ | 1.13 |
Area of application
Tour
80
Wettkampf
Sitting position
upright
66
stretched
0
33
66
100
Tests & Reviews
Equipment
| Rear brakes | SRAM Red |
| Front brakes | SRAM Red |
| Brakes | SRAM Red |
| Front brake disc | 160 |
| Rear brake disc | 160 |
| Drivetrain | SRAM Red XPLR AXS |
| Shift levers | SRAM Red XPLR AXS |
| Drivetrain type | Derailleur |
| Number of gears | 13 |
| Fork | Specialized S-Works FACT Carbon |
| Crankset | SRAM Red Powertap |
| Sprocket | SRAM Red XPLR |
| Handlebar | Specialized Roval Terra Cockpit |
| Stem | Specialized Roval Terra Cockpit |
| Saddle | Specialized S-Works Power with Mirror |
| Seatpost | Specialized S-Works Crux Carbon |
| Wheelset | Roval Terra Aero CLX |
| Wheel size | 28"/622mm |
| Front tire | Specialized Pathfinder TLR 45-622 |
| Rear tire | Specialized Pathfinder TLR 45-622 |
