Canyon Lux CF Trail X0 AXS
Model: Lux CF Trail X0 AXS
Model year: 2026
Category: Fully
Frame material: Carbon
Wheel size: 29"/622mm
Test result
| Property | Weighting | Grade |
|---|---|---|
| Riding behavior | 65% | 2,5 |
| Uphill riding behavior | 13% | 1,5 |
| Uphill suspension efficiency | 10% | 2,0 |
| Playfulness | 12% | 1,8 |
| Downhill riding behavior | 10% | 2,8 |
| Downhill suspension (fork + shock) | 20% | 3,8 |
| Lab | 10% | 2,2 |
| Weight without pedals | 6% | 2,0 |
| Wheel inertia | 4% | 2,5 |
| Equipment | 25% | 1,3 |
| Seatpost drop | 5% | 1,5 |
| Usability / Added value | 5% | 2,0 |
| Quality / Craftsmanship | 5% | 0,5 |
| Equipment quality | 5% | 1,3 |
| Bottle cage volume | 5% | 1,0 |
| Final grade | 2,2 |
Strengths and weaknesses
Radar chart rating: Uphill, Playfulness and Downhill refer to riding behavior. The larger the value, the better the suitability. Equipment refers to the quality of components. Propulsion: Total weight and wheel inertia.
Geometry - measurements overview
H
I
N
M
B
D
P
G
F
E
O
L
A
XL
| A - Top tube length | 650 mm |
| B - Seat tube length | 480 mm |
| D - Standover height | 794 mm |
| E - Chainstay length | 440 mm |
| F - Bottom bracket height | 336 mm |
| G - Wheelbase | 1263 mm |
| H - Stem length | 50 mm |
| I - Head tube length | 125 mm |
| L - BB offset | -37.5 mm |
| M - Stack | 641 mm |
| N - Reach | 476 mm |
| O - Seat angle | 75.3 ° |
| P - Head angle | 64.3 ° |
| Handlebar width | 760 mm |
Sitting position
stretched
balanced
compact
0
33
66
100
Frame stiffness front
very soft
5.84 N/mm
very hard
0
5
10
15
Frame stiffness rear
very soft
15.71 N/mm
very hard
0
10
20
30
Serviceability
weak
12.5
good
0
5
10
15
| Wheel inertia | 3.480,1 kg/cm² |
| Wheel weight | 4.427 kg |
Wheel inertia: BIKE measurement. The lower the value, the better the acceleration.
Frame stiffness: BIKE measurement. Lateral stiffness in N/mm measured separately for front and rear triangle. Front includes fork.
Wheel weight: BIKE measurement. Wheel weight per set with tires, cassette, brake disc.
Tests & Reviews
Equipment
| Rear brakes | SRAM Motive Ultimate |
| Front brakes | SRAM Motive Ultimate |
| Brakes | SRAM Motive Ultimate |
| Front brake disc | 180 |
| Rear brake disc | 180 |
| Drivetrain | SRAM X0 Eagle AXS Transmission |
| Shift levers | SRAM AXS Rocker Paddle |
| Drivetrain type | Derailleur |
| Number of gears | 12 |
| Fork | Fox 36SL Float Factory |
| Rear shock | Fox Float Factory |
| Fork travel (mm) | 140 |
| Rear shock travel (mm) | 125 |
| Crankset | SRAM X0 Eagle Transmission Powertap |
| Sprocket | SRAM XS 1295 |
| Drive type | Chain |
| Handlebar | Race Face ERA |
| Grips | Ergon GXR |
| Stem | Race Face Turbine SL |
| Saddle | Ergon BMR |
| Seatpost | Fox Transfer Factory |
| Wheel size | 29"/622mm |
| Rims | Canyon XC 30 CF |
| Front tire | Maxxis Dissector Exo Protection TR 29 x 2.40 |
| Rear tire | Maxxis Rekon Exo Protection TR 29 x 2.40 |
