Info www.sram.com
Prices crankset/sprocket/chain¹ 220/248/28 Euro
Prices replacement blades¹ 60,00 Euro
Variants 30, 32, 34, 36, 38 teeth; crank lengths: 170 and 175 mm
Leaf Aluminium, 32 teeth, 56 g
Pinion set Steel/aluminium milled/riveted, 10-42
Chain Steel, 118 links, 5.66 mm
Chain fastener Chain lock
Crank/pinion/inner bearing weight 699/312/111 g
Weight chain 116 links 262 g
Total weight gearbox 1384 g
Chain/joint elongation 0.037 mm
RATING
Drive weight (25 %) 6 (max. 10 points)
Pinion wear (25 %) 10 (max. 10 points)
Leaf wear (25 %) 6 (max. 10 points)
Chain wear (25 %) 6 (max. 10 points)
Conclusion Cheaper alternative to the XX1. The gearbox is just under 200 g heavier, but functionally equivalent, and the sprockets are very wear-resistant. The chain shows a little more elongation, but is still at a good level. The chainrings wear in the same way as those of the XX1.
BIKE judgement² GOOD
Road prices for wearing parts
²The BIKE judgement reflects the laboratory measurements and the subjective impression of the test riders. The BIKE judgement is independent of price.
BIKE judgements: super, very good, good, satisfactory, with weaknesses, unsatisfactory.
