Transition Regulator CX XT
Model: Regulator CX XT
Model year: 2026
Category: Fully
Frame material: Carbon
Weight: 21.62 kg
Permissible total weight: 150 kg
Test result
| Property | Weighting | Grade |
|---|---|---|
| Riding behavior | 60% | 2,1 |
| Uphill riding behavior | 20% | 2,0 |
| Playfulness | 12% | 1,5 |
| Downhill riding behavior | 12% | 2,5 |
| Downhill suspension (fork + shock) | 16% | 2,5 |
| Lab | 10% | 2,0 |
| Weight without pedals | 5% | 1,5 |
| Range | 5% | 2,5 |
| Equipment | 15% | 1,9 |
| Seatpost drop | 3% | 0,5 |
| Usability / Added value | 3% | 3,5 |
| Quality / Craftsmanship | 3% | 0,5 |
| Equipment quality | 3% | 1,9 |
| Bottle cage volume | 3% | 3,0 |
| Motor | 15% | 1,6 |
| Motor power | 7% | 1,5 |
| Motor riding behavior | 5% | 1,3 |
| Motor controls | 3% | 2,5 |
| Final grade | 2,0 |
Strengths and weaknesses
Radar chart rating: Uphill, Playfulness and Downhill refer to riding behavior. The larger the value, the better the suitability. Equipment refers to the quality of components. Range: Measured in standardized field test.
Geometry - measurements overview
I
P
D
O
G
F
E
L
B
M
A
N
H
| A - Top tube length | 615 mm |
| B - Seat tube length | 445 mm |
| D - Standover height | 795 mm |
| E - Chainstay length | 452 mm |
| F - Bottom bracket height | 333 mm |
| G - Wheelbase | 1275 mm |
| H - Stem length | 40 mm |
| I - Head tube length | 125 mm |
| L - BB offset | -40 mm |
| M - Stack | 648 mm |
| N - Reach | 469 mm |
| O - Seat angle | 77.6 ° |
| P - Head angle | 63.8 ° |
| Handlebar width | 800 mm |
Sitting position
stretched
balanced
compact
0
33
66
100
Serviceability
weak
6.5
good
0
5
10
15
| Battery weight | 3,07 kg |
| Wheel weight | 5.703 kg |
Battery weight: BIKE measurement. Battery weight may include cover.
Wheel weight: BIKE measurement. Wheel weight per set with tires, cassette, brake disc.
Tests & Reviews
Equipment
| Rear brakes | TRP E.2.3 |
| Front brakes | TRP E.2.3 |
| Front brake disc | 203 |
| Rear brake disc | 203 |
| Front brake lever | TRP Evo Pro |
| Rear brake lever | TRP Evo Pro |
| Drivetrain | Shimano XT |
| Shift levers | Shimano XT |
| Drivetrain type | Derailleur |
| Number of gears | 12 |
| Fork | Rock Shox ZEB Ultimate |
| Rear shock | Rock Shox Super DeLuxe Ultimate |
| Fork travel (mm) | 160 |
| Rear shock travel (mm) | 150 |
| Bottom bracket | Bosch |
| Crankset | SRAM S 1000 |
| Sprocket | Shimano XT |
| Drive type | Chain |
| Headset | FSA |
| Seatpost | One UP Dropper Post |
| Seat clamp | Bell |
| Wheelset | DT-Swiss H 1900 Hybid |
| Front tire | Schwalbe Magic Mary Trail Pro TLR Ultra Soft Radial 29 x 2.50 |
| Rear tire | Schwalbe Magic Mary Gravity Pro TLR Soft Radial 27.5 x2.50 |
| Motor manufacturer / model | Bosch Performance CX |
| Motor type | up to 25 km/h |
| Motor position | Mid-engine |
| Display | Bosch System Controller |
| Control unit | Bosch Mini Remote |
| Battery | Bosch Power Tube 600 |
| Battery capacity (Wh) | 600 |
| Charger | Bosch 4 Ah charger |
