Rear brakes	Formula Cura, 2-piston, hydraulic disc brake
Front brakes	Formula Cura, 2-piston, hydraulic disc brake
Brakes	Front: Shimano BR-M6000, 2-piston, hydraulic disc brake; Rear: Shimano BR-M6000, 2-piston, hydraulic disc brake
Front brake disc	Formula, 180 mm, 6-hole
Rear brake disc	Formula, 180 mm, 6-hole
Brake levers	Shimano BL-T6000, adjustable brake lever, 3-finger
Frame	27.5", 6061 alloy, integrated battery, Boost
Drivetrain	SRAM GX Eagle, 12-S
Shift levers	SRAM GX Eagle, Single Click
Fork	SR SUNTOUR Mobie25 LOR, air, 63 mm, tapered
Bottom bracket	SRAM X-Sync Eagle, 38 T
Crankset	R Raymon EC40, forged aluminium, ISIS
Sprocket	SRAM PG-1230, 10-50 T
Drive	SRAM GX Eagle
Headset	R Raymon ZS44/ZS56
Handlebar	R Raymon Riser 31.8 mm, 640 mm, sweep: 35°, rise: 25 mm
Grips	R Raymon Ergo, screw-type handles
Stem	R Raymon 31.8, Ahead, adjustable
Saddle	R Raymon Ergo
Seatpost	R Raymon, 31.6 mm, 300 mm, patent
Seat clamp	R Raymon 35, quick-release
Wheelset	27.5"/584mm
Rims	Mach 1 TRUCKY 30, eyelet-fastened
Tires	Schwalbe Johnny Watts, Performance, 60-584, 27.5x2.35
Front hub	R Raymon DA210F, Centre Lock, 15x110 mm, thru-axle
Rear hub	R Raymon DA210R, Centre Lock, 12x148 mm, thru-axle, MS
Spokes	Mach1, stainless steel
Pedals	R Raymon, aluminium
Front light	Litemove HKSE-150, 150 lx, 750 lm, parking light
Rear light	AXA Blueline E, parking light
Mudguards	Eurofender Tempo
Kickstand	Ursus MOOI, rear kickstand KSA40, adjustable
Rack	R Raymon Tour, MIK, load capacity 25 kg
Motor manufacturer / model	Yamaha PW-X3, 250 W, 85 Nm
Display	Yamaha Display C, LCD display, Bluetooth, Micro-USB
Control unit	Yamaha C
Battery	Simplo, 630 Wh, 36 V
Battery capacity (Wh)	630
Charger	Simplo quick charger, 4 A
