| Brakes | Shimano XT BR-M8120, Hydr. Disc Brake (203/203) |
| Frame | Aluminium Superlite, Gravity Casting Technology, Efficient Comfort Control, FSP 4-Link, Agile Comfort Geometry, Boost 148, Full Integrated Battery |
| Frame material | Aluminium |
| Drivetrain | Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed - Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate |
| Shift levers | Shimano Deore SL-M6100-IR, Direct Attach, Rapidfire-Plus |
| Drivetrain type | Derailleur |
| Fork | Fox 34 Float AWL, 2-position Sweep-Adjust RAIL damper, tapered, 15x110mm, e-bike optimised, 120mm |
| Rear shock | Fox Float Rhythm RC, 185 x 52.5 mm, Open/Firm mode, trunnion mount – top: 54 mm trunnion mount, bottom: 22.2 x 8 mm |
| Fork travel (mm) | 120 |
| Crankset | ACID MTB Hybrid Pro, 38T |
| Sprocket | Shimano Deore CS-M6100, 10-51T |
| Drive | KMC e12 |
| Drive type | Chain |
| Headset | ACROS AZF-1034, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), X-Connect Interface |
| Handlebar | CUBE Rise Trail Bar 35 |
| Grips | ACID Hybrid Perform |
| Stem | CUBE Performance Stem E-MTB 35, FPI-Link |
| Saddle | ACID Venec EMTB Plus 145 |
| Seatpost | CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm |
| Wheel size | 29"/622mm |
| Rims | CUBE EX30, 32H, Disc, Tubeless Ready |
| Tires | Schwalbe Smart Sam, Performance, 2.6 / 29" |
| Front hub | CUBE Engineered By Newmen, 15mm, Boost, Centrelock |
| Rear hub | CUBE Engineered By Newmen, 12mm, Boost, Centrelock |
| Pedals | ACID PP MTB |
| Motor manufacturer / model | Bosch Drive Unit Performance Line CX 85Nm (BDU38), Smart System |
| Control unit | Bosch Purion 200 w/ Integrated Display |
| Battery | Bosch PowerTube 800 |
| Battery capacity (Wh) | 800 |
| Charger | Bosch 2A |
