Canyon Torque:ON CF 9

The Canyon Torque:ON CF 9 is a state-of-the-art e-mountain bike, positioned in the premium segment with a price tag of 7,499 EUR. The bike’s frame is made of carbon and contributes to its total weight of 24.6 kg. The model is fitted with high-quality components that ensure optimum off-road performance.

The brakes are Shimano DEORE XT M8120, fitted with brake discs up to 220 mm in diameter. At the front, a 220 mm diameter Shimano Centre Lock brake disc is used. The Shimano DEORE XT M8100 system handles the gear changes, which, in combination with a 12-speed Shimano Deore XT shifter, enables precise and reliable gear changes.

The Fox X2 Factory shock and the fork, with 180 mm of travel, offer excellent damping characteristics and ensure a comfortable riding experience on challenging trails. The front light consists of a reflector set, which provides additional safety. The VP-536 pedals and the Shimano STEPS HOLLOWTECH e-MTB crankset complete the drivetrain.

The handlebars, a Handlebar HB0057, are 780 mm wide and have a 30 mm rise. They are fitted with Canyon Lock-On grips and are mounted on a Canyon:ON ST0031 stem with a clamp diameter of 35 mm. The tyres are Maxxis Assegai 3C MaxxGrip, fitted to a DT Swiss HFR1700 wheelset measuring 29"/622 mm.

The saddle is a Fizik Gravita Alpaca X5, mounted on an Iridium dropper seatpost with a length of 425 mm. Additional equipment includes a Canyon Organza Bag, a 15 mm Wrench Tool, a Canyon Smallbox and a QSG 034-V03 M124 TRQ[ON].

At the heart of the bike is the Shimano EP801 motor, whose battery varies depending on the chosen configuration. The charger is a Canyon BC001. With a reach of 450 mm, a stack of 639 mm and a seat tube length of 395 mm, the bike’s geometry offers a balanced riding position. The seat tube angle is 77 degrees, the head tube length is 105 mm, and the spacers are 20 mm. The standover height is 738 mm and the crank length is 165 mm. The wheelbase is specified as 1 mm.

Overall, the Canyon Torque:ON CF 9 offers an impressive combination of advanced technology and high-quality components, making it the ideal companion for demanding off-road adventures.
