Cannondale Moterra 1
The Cannondale Moterra 1 is the epitome of a successful all-mountain bike. It carries the rider with ease uphill and provides a safe ride downhill at all times. Comfort, safety and range are more pronounced on the Cannondale than on any other bike in the test. The spec leaves nothing to be desired, and the price is fair – with the competition, you often get less for the same price.
Test result
| Property | Weighting | Grade |
|---|---|---|
| Riding behavior | 60% | 2,0 |
| Uphill riding behavior | 20% | 1,5 |
| Playfulness | 12% | 3,5 |
| Downhill riding behavior | 12% | 2,0 |
| Downhill suspension (fork + shock) | 16% | 1,5 |
| Lab | 10% | 2,1 |
| Weight without pedals | 5% | 3,3 |
| Range | 5% | 1,0 |
| Equipment | 15% | 2,0 |
| Seatpost drop | 3% | 1,0 |
| Usability / Added value | 3% | 3,8 |
| Quality / Craftsmanship | 3% | 0,5 |
| Equipment quality | 3% | 1,5 |
| Bottle cage volume | 3% | 3,0 |
| Motor | 15% | 1,5 |
| Motor power | 7% | 1,5 |
| Motor riding behavior | 5% | 1,3 |
| Motor controls | 3% | 1,8 |
| Final grade | 1,9 |
Strengths and weaknesses
Radar chart rating: Uphill, Playfulness and Downhill refer to riding behavior. The larger the value, the better the suitability. Equipment refers to the quality of components. Range: Measured in standardized field test.
Geometry - measurements overview
| A - Top tube length | 612 mm |
| B - Seat tube length | 420 mm |
| D - Standover height | 828 mm |
| E - Chainstay length | 460 mm |
| F - Bottom bracket height | 342 mm |
| G - Wheelbase | 1290 mm |
| H - Stem length | 45 mm |
| I - Head tube length | 135 mm |
| L - BB offset | -33 mm |
| M - Stack | 655 mm |
| N - Reach | 470 mm |
| O - Seat angle | 77.9 ° |
| P - Head angle | 64.1 ° |
| Handlebar width | 780 mm |
| Battery weight | 3,95 kg |
| Wheel weight | 5.996 kg |
Battery weight: BIKE measurement. Battery weight may include cover.
Wheel weight: BIKE measurement. Wheel weight per set with tires, cassette, brake disc.
Altitude range: Determined in standardized field test. Highest support level, 90 kg rider weight, 150 watts pedaling power. Gray arrow indicates additional altitude meters in emergency mode.
Tests & Reviews
Equipment
| Rear brakes | Magura MT7 |
| Front brakes | Magura MT7 |
| Front brake disc | 220 |
| Rear brake disc | 203 |
| Front brake lever | Magura MT7 |
| Rear brake lever | Magura MT7 |
| Drivetrain | SRAM X0 Eagle AXS drivetrain |
| Shift levers | SRAM AXS Pod Controller |
| Drivetrain type | Derailleur |
| Number of gears | 12 |
| Fork | Fox 38 Float Factory |
| Rear shock | Fox Float X Factory |
| Fork travel (mm) | 160 |
| Rear shock travel (mm) | 150 |
| Bottom bracket | Bosch |
| Crankset | eThirteen e-spec Helix |
| Sprocket | SRAM XS 1275 |
| Drive type | Chain |
| Headset | Cannondale |
| Handlebar | Hollowgram Save Riser Bar |
| Grips | Cannondale Taper Ridge |
| Stem | Cannondale Trail Heads Up |
| Saddle | Fizik Terra Aidon |
| Seatpost | Cannondale Down Low |
| Seat clamp | Clamp |
| Wheelset | DT-Swiss H 1900 Spline 30 |
| Front tire | Continental Kryptotal Fr Enduro Soft 29 x 2.40 |
| Rear tire | Continental Kryptotal Re Enduro Soft 29 x 2.40 |
| Motor manufacturer / model | Bosch Performance CX |
| Motor type | up to 25 km/h |
| Motor position | Mid-engine |
| Display | Kiox 500 |
| Control unit | System Controller-Mini Remote |
| Battery | Bosch Power Tube 800 |
| Battery capacity (Wh) | 800 |
| Charger | Bosch 4 Ah charger |
