Bergamont E-Revox 3 26 anthracite/yellow

The "E-Revox 3 26 anthracite/yellow" from Bergamont, released in 2020, is an e-bike available for 2,199 EUR. It features a robust frame made from ultra-lightweight AL-6061 tubing and an integrated PowerPack battery. Weighing in at 20 kg, the bike is relatively light for an e-bike yet still delivers solid performance.

The braking system consists of Shimano hydraulic disc brakes (BR-MT200) with 160 mm rotors at both the front and rear, ensuring reliable braking power. The brake levers are also from Shimano (BL-MT200), ensuring consistent and precise braking performance.

The gear system comprises a 9-speed Shimano derailleur (RD-M4000, Shadow) and Shimano SL-M2010 shift levers, which are Rapidfire Plus levers. This enables fast and precise gear changes. The fork is a Suntour XCR32 air fork with 100 mm of travel and adjustable rebound damping, ensuring a comfortable ride even on uneven terrain.

Other features include VP pedals, a Bosch bottom bracket with ISIS mount, an FSA CK-200 crankset with an aluminium chain guard and 36 teeth, and a Shimano CS-HG200-9 cassette with 11–34 teeth. Power is transmitted via a KMC e9S chain.

The handlebars are Syncros M15 flat bars with a width of 640 mm, combined with Syncros MTB grips and a 50 mm Syncros stem. The headset is a BGM A-Headset. The rims are Mach1 650 Disc rims, which are tubeless-ready and 23 mm wide. The tyres are Kenda Slant Six in size 26x2.35", which ensure good traction and stability. The hubs are by Shimano, fitted with CentreLock disc mounts and quick-release skewers, and the spokes are made of black steel.

The saddle and seatpost are also by Syncros, providing additional comfort. The e-bike is powered by a third-generation Bosch Drive Unit Active Line Plus motor with an output of 250 W and a voltage of 36 V, enabling a maximum speed of 25 km/h. The battery is a Bosch 36 V Li-Ion PowerPack with a capacity of 400 Wh, and the display is a Bosch Purion.

Overall, the Bergamont “E-Revox 3 26 anthracite/yellow” offers a well-thought-out combination of performance, comfort and reliability, making it an attractive choice for e-bike enthusiasts.
